1. Document identity
State the drawing number, title, revision, release date, and applicable part number. Avoid filenames such as “latest” when a controlled identifier is available.
CONTROL THE APPROVED BUILD DEFINITION
Wire Harness Revision Control Requirements for OEM Projects
Keep the drawing, BOM, pinout, dimensions, labels, test requirements, and approval record aligned before quotation, prototype review, and production.
A revision identifier is useful only when every affected project document points to the same approved technical definition.
Quick answer
For each harness revision, identify the current drawing and revision, matching BOM and connection data, what changed and why, affected quantities or builds, and the approved released definition.
WHY IT MATTERS
A changed part number is not a complete revision record
A wire harness build definition usually depends on several connected documents. A drawing may control dimensions and branch layout, while the BOM identifies components and a connection table defines circuit relationships. Labels, coverings, inspection requirements, packaging notes, and customer approvals may sit in additional files.
If one file changes without the others, the supplier may quote or build against mixed revisions. A controlled revision package gives purchasing, engineering, quality, and manufacturing teams one reference point for review.
Revision control does not replace technical approval. It makes the approved state and open decisions visible so the supplier can review customer requirements without silently choosing between conflicting inputs.
REVISION PACKAGE
Include these six elements with an updated RFQ or release
The exact document set depends on the product and customer system, but the relationships between files should be explicit.
2. Matching BOM
Identify the BOM revision that belongs with the drawing. Separate approved components from proposed alternatives or unresolved sourcing questions.
3. Connection definition
Include the current pin assignment, circuit names, polarity where applicable, connector views, and any intentionally unused positions.
4. Change description
Describe the affected item and the previous and new requirement. A concise change table is easier to review than asking the supplier to compare two complete files without guidance.
5. Effectivity
Define whether the revision applies to a new quotation, an unapproved prototype, future production, or another customer-controlled scope. Confirm disposition separately when earlier material or assemblies may be affected.
6. Approval status
Mark draft, review, and released states clearly. Record the customer-approved definition used for the next supplier action.
CROSS-DOCUMENT ALIGNMENT
Check the change wherever the requirement appears
A connector change may affect the BOM, mating interface, pinout, cable exit direction, labels, and inspection instructions. A length change may affect measurement references, branch dimensions, routing, and packaging. A label revision may affect both artwork and the drawing callout.
Drawing and dimensions
Confirm overall length, branch points, tolerances, orientation, coverings, and identification locations against the current drawing.
BOM and components
Confirm that each component reference corresponds to the released design and that any proposed alternative remains visibly unapproved until confirmed.
Inspection and records
Update project-defined inspection, electrical testing, acceptance, and record requirements when the changed design affects them.
REVIEW TABLE
Use the change type to find dependent information
These examples organize review questions; the customer-approved documents remain the controlling source.
| Change type | Related information to review | Supplier question |
|---|---|---|
| Connector or terminal | BOM, mating interface, cavity use, pin assignment, orientation, wire compatibility | Is the new component approved and is the connection definition updated? |
| Wire or cable | BOM, circuit requirement, color or identification, termination, protection | Which requirements changed and which remain unchanged? |
| Length or branch | Measurement points, tolerance, route, breakout location, installation orientation | Which dimensions control the revised assembly? |
| Label or marking | Text, location, orientation, artwork, revision marking | Which identification file and drawing revision apply together? |
| Inspection requirement | Characteristic, method, acceptance basis, scope, sampling, record need | What project-approved requirement should the supplier quote and follow? |
BUYER WORKFLOW
Control revisions through quotation, prototype, and production review
Before quotation
Send the current revision set and list unresolved decisions. Ask the supplier to identify assumptions and information gaps before finalizing the quotation basis.
Before prototype build
Confirm the drawing, BOM, connection data, quantities, and project-defined inspection requirements that apply to the prototype.
After prototype feedback
Convert approved observations into controlled document changes. Do not rely on comments, photographs, or marked samples alone when the released definition must also change.
Before production support
Confirm the customer-approved revision and communicate effectivity. Review any open component, inspection, or documentation decision for the applicable project.
